B1plus PRO 2-TONE RED EDITION
Please sign in so that we can notify you about a reply
Heart Design. Industrial Made. Hand-Crafted.
Hawk B1plus specially designed for Brompton External 1s-5s Ready.
Free Hub Lock Type you can choose:
1. Brompton C Line C-Clip Lock Type:
a. If using C-Line Cogs External Speed 1s-4s
2. Shimano 11s Cassette Lock Type (compatible: P / T Line):
a. C-Line Cogs / Shimano 9s/10s Cogs: EX 2s-3s
b. Shimano 11s Sprocket & Cogs / P/T-Line Cogs: EX 3s-5s, using Hex 7s cassette=7 Speeds
3. The Front Wheel uses a Hollow Shaft and 2 Types of Shafts available for Rear Wheel.
a. Thread Shaft for C-Line Standard and Compatible with P/T-Line, Rear Wheel using Screw Nuts
b. Hollow Shaft Compatible with C/P/T-Line and Rear wheel using Skewer Or QR
Hawk Tubeless Rim Features
Tubeless Rim Size:
16", 349*18.2mm // Outer Width: 23.2mm
Tubeless Rim Height:
Front Rim Height: 40mm // Rear Rim Height: 40mm
Rim Outer Width:
23.2mm for Comfy & Safe Cycling
Tubeless Rim Shape:
Chubby Toroidal Design for Aerodynamics
Rim Spoke Holes :
Front:16 Holes // Rear: 16 Holes
Rim Spoke Holes Drilling::
Angled Drilling to Fit Spoke to Flange Angle
Tubeless Rim Design:
Tubeless Ready // None Rim Tape Design, Rim Tapes No Longer Required
Tubeless Rim Surface Protection:
- Carbonized Hard-Wear Resistant Tech.
Rim Color Available:
- Glossy Carbonized Black Grey
- Matt Carbonized Black Grey
- 2-Tone Glossy Carbonized Black Grey
- 2-Tone Matt Carbonized Black Grey
Tubeless Rim Process:
- Tubeless Ready & None Rim Tape Design Process.
- Advanced 3D Diamond Milling Tech.( Reduce Rim Weight and 2-Tone Style )
- Silent Project for Valve Hole ( Valve not shaking when cycling )
- Strengthen High Spoke Tension Structural Tech.
- SSC Process ( Short Stopper Control )
- 100% hand-crafted high polish process.
- Carbonized Hard-Wear Resistant Tech.
Tubeless Rim Benfits:
- Keep Rolling Speed Longer When Un-pedaling or City Cruise
- Easily to Maintain Riding Average Cycling Speed.
- Comfy Cycling and Stable Cornering
- No More Rim Tapes
US7075 Low Drag Hubs Features
Hub Shall Material::
One piece of Ultra-Strength 7075 Alloy
7075 Hub Processing:
Precision CNC Machining and Hand High-Polished
7075 Hub Basic Color:
- 7075 Space Black
7075 Hub Optional Color:
- 7075 Optional Colors
- 7075 Red Hot Color
7075 Hub SideCaps Basic Color:
- 7075 Red Hot
7075 Hub SideCaps Optional Color:
- 7075 Optional Colors
- 7075 Matt Black
Axle / Shaft Material:
One piece of Ultra-Strength 7075 Alloy
Front Hub Shaft Type:
- 74mm Hollow Shaft
Rear Hub Shaft Type:
- 112mm Hollow Shaft C/P/T-Line Compatible
- 112mm Thread Shaft C/P/T-Line Compatible
Low Drag Drive Mechanism::
Patented Low Drag 6-pawls independent Mechanism structure
Durable Bearing Type:
Germany and Japan Combine durable Double sealed Deep Groove cartridge bearings
US7075 Hub Advantages:
- Low Drag Drive
- Fasr Acceleration
- Instant Drive
FreeHub Body Type
FreeHub Body:Process:
Forged Ultra high strength 7075 alloy
FreeHub Body Color:
Sand-Blasted Matt Black
FreeHub Body Compatibility :
- Shimano Cassette Lock Type C/P/T-Line Compatible ( Ex 2s-5s )
- C-Clip Lock Type C-Line ( Ex 1s-4s )
- Hex 7s Cassette Compatible
Spokes & Nipples Features
Spoke Material::
Butted and Forged Stainless steel
Spoke Size:& Type:
3.6mm Width, Pull Straight Aero Bladed Spokes
Spoke Count::
Front Wheel: 16pcs // Rear Wheel: 16pcs
Pro Spoke Lacing::
- Radial Lacing at Front Wheel
- Radial Lacing at Rear Non-Drive Side
- Crossed Lacing at Rear Drive Side ( Unique Lacing )
Spoke Design:
- Anti-Rotation Bladed Aero Spokes
- Same Spoke Length at Front & Rear, Easy for Service & maintenance
- Same Spoke angle between Left & RIght Side at Rear Wheel,
Standard Spoke Color:
- XD Black
- 2pcs Red Hot
- 4pcs Laser Engraved Spokes
Optional Spoke Color:
- Optional Color
- 6pcs Laser Engraved Spokes
- 8pcs Laser Engraved Spokes
- 4pcs Red Hot
Nipple Material:
Ultra-Strength 7075 Alloy
Standard Nipple Color:
- 7075 Titanium Dark Grey
- Custom-Made Chrome Ring
Optional Nipple Color:
- Black
- Optional Colors
- Red Hot
Tire Features
Tire Type::
Open Clincher
Valve Holes:Spec:
F/V 6.5mm // Presta Valve
Recommended Tire Size::
23C-44C / 1.0 -1.7 Tires
Recommended Inflation Pressure::
:115 Psi / 8 Bar
Recommended Max Pressure::
130 Psi / 9 Bar
Wheel System Features
Wheel Assemble::
100% Pro hand-built wheels by Experienced Pro Master
Wheel Logos:
Oversized Laser Engraved Logos with Sticker
Wheel Design Advantages::
- 3D Diamond Milling Tech.
- Anti-Rotation Bladed Aero Spokes
- Low Drag Drive Mechanism System
- Non-Rim Tapes Designed Wheels
- Silent Project for Valve Extender
- Tubeless Ready Wheel System
Wheel Standard Package::
- 105 Black Skewer for Front Hub
- Convert Kits for Brompton Ex 2s-5s
- Hand-made bag for wheel package
- Hand-Made Wheel Cover
- RVE-30 Black Removable Core Valve Alloy Extender
- Original Spare Parts and Manuals
Wheel Weight :
Hawk B1plus 1078g / pair
